Specification
Key Features | ||
Data Rate | 2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps |
|
Antenna | 4 External Antennas | |
Button | Reset Button WPS/Wi-Fi On/Off Button Power On/Off Button |
|
Frequency | 2.4GHz and 5GHz | |
Wireless | IEEE 802.11n/g/b 2.4GHz IEEE 802.11ac/n/a 5GHz |
|
Interface | 4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port |
|
Network Standard | 5GHz: 11a 54M: -73dBm 11ac VHT20 MCS8: -68dBm 11ac VHT40 MCS9: -64dBm 11ac VHT80 MCS9: -60dBm 2.4GHz: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71d |
|
Encryption | 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption | |
Ports | 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports |
|
Others | 1200 sq ft to 1500 sq ft Maximum Area Open Space Coverage Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing CE, FCC, RoHS 2.4GHz guest network × 1 5GHz guest network × 1 Supports IPv4 and IPv6 DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding Parental Control, Local Management Control, Host List, Access Schedule, Rule Management PPTP, L2TP, IPSec DynDns, Comex, NO-IP Virtual Server, Port Triggering, UPnP, DMZ Server, Client, DHCP Client List, Address Reservation Access Control Local Management Remote Management Dynamic IP/Static IP/PPPoE/ BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) |
|
Operating System Support | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8/8.1/10 MAC OS, NetWare, UNIX or Linux |
|
Power Source | ||
Power Mode | CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm External Power Supply-9VDC / 0.85A |
|
Physical Dimension | ||
Dimension | 9.1 x 5.7 x 1.5 in. (229.87 x 144.19 x 36.85 mm) | |
Manufacturer warranty | ||
Warranty | 01 year warranty |
